General Information
| Part # | 340137 |
| type | PL900SM-N Connector |
| Circuit Count | 14 |
| Contact Plating | Gold |
| Contact Size | 22 |
| Contact Termination | Crimp/Solder |
| Contact Type | Machined, Gold Plated |
| Coupler Color | Gray |
| Environmentally Sealed | Yes |
| Housing Color | Blue |
| Housing Material | Plastic |
| Housing Size | 0.900" |
| Housing Style | Plug, Cable-Mount |
| Latch Mechanism | Pulse-Lok |
| Mating Key | 2 |
| Maximum Cable Diameter | 0.5 |
| Maximum Wire Gauge | 22 |
| Operating Current | 5 |
| Operating Voltage | 300 V RMS |
| RF Immunity | No |
| Series | PL900 |
| Series Style | Plastic |
PL900 Components
| Plug Housing | Coupler Assembly |
| Plug Housing | Coupler Assembly |
| Plug Core Insulator | 1 |
| Interface Seal | 1 |
| Pin Contact | 14 |
Mating Connectors
Part Number |
Type |
Housing Style |
Housing Material |
Housing Color |
|---|---|---|---|---|
PL900SM-N Connector |
Receptacle, Cable-Mount |
Plastic |
Blue |
|
PL900SM-N Connector |
Receptacle, Rear Panel-Mount |
Plastic |
Blue |
|
PL900SM-N Connector |
Receptacle, Rear Panel-Mount |
Plastic |
Blue |
